Specification

Discharge current: 15A/35A/50A
Charging current (same port): ≤10A/≤20A/≤30A
Main circuit conduction internal resistance: ≤15MΩ/≤10MΩ/≤6MΩ
Discharge overcurrent protection: 50±10A/100±20A/150±30A

Overcharge protection
Detection voltage: 3.65±0.025V
Detection delay: 1000±500MS
Release voltage: 3.45±0.05V

Over discharge voltage protection
Detection voltage: 2.35±0.1V
Detection delay: 1000±500MS
Release voltage: 2.7±0.1V

Balanced voltage
Detection voltage: 3.45±0.025V
Detection delay: 100±50MS
Balance current: 35±5MA

Discharge overcurrent protection
Detection voltage: 100±15MV
Detection delay: 1000±500MS
Current protection: 50A±10A 100A±20A 150A±30A

Short circuit protection
Trigger condition: external short circuit
Detection delay: ≤350US
Release condition: disconnect the load

Self-consumption
Working power consumption: ≤40UA
Sleep over-discharge power consumption: ≤10UA
Operating temperature range: -20/+80°C
