100A Waterproof Brushless ESC Speed Controller 2S-4S Lipo NiMH Fit 3650 3660 Motor For 1/10 RC Car Double Plug

Reference: (SKU): WP-S8A-RT

In stock

Item : 100A Waterproof Brushless ESC WP-S8P-RTR

1 ESC SPECIFICATIONS

1.1 Output capacity: continuous current 100A, instantaneous current 760A;

1.2 Power input: 6-12 nickel-metal hydride / nickel-cadmium battery pack or 2-4 lithium battery pack;

1.3 BEC output: 6V / 3A (switching regulator mode switching mode)

1.4 internal resistance: 0.0004 ohms;

1.5 support motor type: no sense of brushless (also supports a sense of brushless motor running in the non-sense mode);

1.6 Support motor T number:

2 lithium or 6 nickel-hydrogen: KV ≤ 6000;

3 lithium or 7-9 nickel-hydrogen: KV ≤ 4000;

4 lithium or 10-12 nickel-hydrogen: KV ≤ 3000;

1.7 Applicable models: 1/10 four-wheel drive short card / big foot, 1/8 two-wheel drive and four drive short card / off-road;

1.8 Dimensions: 60mm (length) * 45mm (width) * 42mm (high);

Connector: 4mm Banana

Package Contents :

Package: 1 pc
