Motor

Mode: 1102 10000KV

Configu-ration:9N12P
Stator Diamter:11mm
Stator Length:2mm
Shaft Diameter:Φ1.5mm
Dimension(Dia.*Len):Φ13.5mm*16mm
Weight(g):2.8g
No.of Cells(Lipo):1-2S

 Propellers

Blades:3

Material:PC

Pitch:2.3Inch

Prop Disk Diameter:52.17mm

Center Thickness:5mm

Center Hole Inner diameter:1/1.5mm

3 Holes

Max Prop Width:8.94mm

Weight:0.88g

 Flight controller

 (Frsky SPI RX version) CRAZYBEEX FR V2.2 FC  Firmware target: CrazybeeF4FR

(Flysky SPI RX version) CRAZYBEEX FS V2.2 FC Firmware target: CrazybeeF4FS

(No receiver version) CRAZYBEEX PNP

V2.2 Firmware target:CrazybeeF4DX

MCU:STM32F411CEU6 (100MHZ, 512K FLASH)
Sensor: MPU-6000(SPI connection)
Board Size: 28.5 * 28.5MM
Power Supply: 1-2S Battery Input (DC 2.9V-8.7V)
Built-in 5A(each) Blheli_S 4in1 ESC Dshot600 Ready
Built-in Betaflight OSD(SPI Control)
Built-in 5.8G VTX
Built-in SPI Frsky/Flysky Receiver or No Receiver
Built-in 5V 1A BEC
Built-in Voltage Detection

 Onboard 4in1 ESC

MCU upgraded to EFM8BB21

Power Supply: 1S LiPo/LiPo HV

Current: 5A Continuous, Peak 6A (3 seconds)
Support BLHeliSuite Programmable
Factory Firmware: S_H_50_REV16_7.HEX
Default Protocol: DSHOT600

 Onboard Frsky SPI D8 receiver Version

Compatible SPI BUS Receiver Frsky D8

Compatible Non EU transmitter D8 model

Channels: 8CH
Failsafe Support
No Ground Interference ( Transmitter and receiver 1 m from the ground): 100m~200m

Onboard 5.8g VTX

Output Power: 25mw
Frequency: 40CH
Input Voltage: 3.3V 5.5V
Current Consumption: 300mA(type)
Frequency: 5.8GHz 5bands 40 channels
With Race Band

Smartaudio Ready

Caddx ANT lite 1200tvl Camera

Image Sensor: 1/3" CMOS Sensor

Horizontal Resolution 1200 TVL

TV System NTSC/PAL switchable

MENU SUPPORT

IMAGE: 16:9

Synchronization Internal

Electronic Shutter PAL: 1/50~100,000; NTSC: 1/60~100,000

S/N Ratio >52dB (AGC OFF)

Video Output: CVBS

Lens: 2.1mm

Min. Illumination 0.001Lux@F1.2

Auto Gain Control:  YES

BLC:  YES

WDR: Global WDR

DNR: 2 DNR

Dimensions 14mm*14mm

Wide Power Input: DC 3.7-18V

Work Temperature: -20℃~+60℃

Work Humidity: 20%~80%

Weight: 1.5g (N.W.)
