• The BMS needs to be activated before use, and the BMS can be activated by charging the board once.

charging protection

• Single overcharge voltage: 4.25V±0.025V

• Single overcharge recovery voltage: 4.15V±0.1V

• Rated charging current: 50A/60A/100A/120A

• Charging peak current: 80A/100A/150A/200A

• Charging protection temperature: -5℃~55℃

discharge protection

• Monomer over-discharge voltage: 2.7V±0.1V

• Monomer over-discharge recovery voltage: 3.0V±0.1V

• Rated discharge current: 50A/60A/100A/120A

• Discharge peak current: 175A/200A/350A/400A

• Discharge protection temperature: -10℃~75℃

• Balance current: 42mA

• Short circuit protection: yes

• Short circuit recovery condition: charge recovery/disconnect load

• B-, P- conduction internal resistance: ≤10mΩ

size

• 50A/60A: 128*63*10mm

• 100A/120A: 128*63*15mm
