Input voltage:(2-3S Lixx) 4-10Ni-Mh

 BEC:5V  3amp Running

current:30A(Output:  Continuous 30A, Burst 40A up to 10 Secs.)

Size:  45.0*24.0*9.0mm

Weight: 28g.

Programmable Items:

1. Brake Setting£ΊEnabled / Disabled, default is Disabled

2. Battery Type£ΊLi-xx(Li-ion or Li-poly) / Ni-xx(NiMH or NiCd)£¬default is Li-xx.

3. Low Voltage Protection Mode(Cut-Off Mode)£Ί Soft Cut-Off (Gradually reduce the output power) or Cut-Off (Immediately stop the output power). Default is Soft Cut-Off.

4. Low Voltage Protection Threshold(Cut-Off Threshold)£ΊLow / Medium / High, default is Medium.

1) For lithium batteries, the number of battery cells is calculated automatically. Low / medium / high cutoff voltage for each cell is: 2.6V/2.85V/3.1V. For example: For a 3 cells lithium pack, when ΅°Medium΅± cutoff threshold is set, the cut-off voltage will be: 2.85*3=8.55V.

2) For nickel batteries, low / medium / high cutoff voltages are 0%/45%/60% of the startup voltage (i.e. the initial voltage of battery pack), and 0% means the low voltage cut-off function is disabled. For example: For a 10 cells NiMH battery, fully charged voltage is 1.44*6=8.64V, when ΅°Medium΅± cut-off threshold is set, the cut-off voltage will be:8.64*50%=4.3V΅£

5. Startup Mode£ΊNormal /Soft /Super-Soft, default is Normal. Normal is preferred for fixed-wing aircraft. Soft or Super-soft are preferred for helicopters. The initial acceleration of the Soft and Super-Soft modes are slower in comparison, usually taking 1 second for Soft startup or 2 seconds for Super-Soft startup from initial throttle advance to full throttle. If the throttle is closed (throttle stick moved to bottom) and opened again (throttle stick moved to top) within 3 seconds of the initial startup, the restart-up will be temporarily changed to normal mode to get rid of the chances of a crash caused by slow throttle response. This special design is very suitable for aerobatic flight when quick throttle response is needed.

 6. Timing£ΊLow / Medium / High, default is Low. Usually, low timing value can be used for most motors. We recommend the Low timing value for 2 poles motor and Medium timing value for motors with more than 6 poles to get a high efficiency. For higher speed, High timing value can be chosen.

-----------------------------------------------------------------------

 Weight 28g) (Dimensions 45.0*24.0*9.0mm) (Current(A)30-40) (BEC 3A)(PWM 8K) (Li-Po 2-3) (Ni-Mh/Ni-cd 4-10Ni-Mh) Features: BEC: 3A Constant current 30A Max 40A <10s Li-Poly 2-3 cells; Ni-MH 4-10 cells Auto Detect Break On/Off; Auto Low battery Slow down at 3.0V/cell Lipo, cut-off at 2.9V/cell Lipo *Note: Timing and P WM can be programmable if required. Currently we just want to keep this product simple and easy to use for Beginners. According to our experience Too complex of the small ESCs only make more trouble and need more effort of supporting.
