Constant current 60A Max 80A <10s
Size : 65 x 39 x 13mm
Weight : 61g
High Voltage Li-Poly 2-7 cells, Ni-MH 6-20 cells
Low resistant 0.0014 ohms
Dynamic braking
BEC : OPTO
Auto shut down when lose signal
Slow down at 3.0V per cell Lipo, Cut-off at 2.9V per cell Lipo 0.8V Nimh   User programming options
Battery Setting
Throttle Range
Brake Setting 4 options
Direction and Cutoff Type
Timing Mode Setting: 1º /7º /15º/30º
PWM Setting: 8K/16K

Important Note: this ESC is Opto, without BEC supplying power to your Receiver, you need extra power source for your receiver. You can use a UBEC, a voltage regulator, or extra batteries as the power source for your receiver. If you hear the music tone repeat again and again for more than 3 times, you may need to check your power source to the receiver.
