· Weight: 38g
· Size: 52x25x10mm
· Constant Current: 60A
· Input: 2 to 5 Li-Po/6 to 16 Ni-MH/Ni-Cd

[1] Easy setting and easy operation. Waterproof design is special for boat.

[2] It can be connected with program box (Pro-box) with LED display and all kinds of parameter can be set at customers' convenience.

[3] 2-5 Li-poly batteries can be set through Pro-box, cut off protection voltage for each piece of Li-poly battery can be set at 2.0-3.2V and can be adjusted at each 0.1V; The cut off protection voltage for NiCad/nickel-hydrogen battery can be set at 0.4-1.0V with each 0.1V adjustable, default setting is 2 Li-poly cells.

[4] Time mode is(0-30)degree and can be adjusted at each degree.

[5] Three adjustable frequency,8KHZ16KHZ32KHZ can match with different kinds and brands of motors.

[6] Three kinds of reflection curve (logarithmic curve/ linear / exponential type curve) for throttle/, adjusting different linear curve comes with different speed up feeling.

[7] Customers can get perfect throttle setting by integrating 3 speed up control (fast/medium/slow) with different throttle curve. *

[8] Locked rotor protection can auto-cut off power when locked rotor happen to protect the speed controller from damaging.

[9] Safety power-on function can protect users from hurting by sudden motor rotor, no matter the throttle is on which position, the motor can not be started up instantly.

* Reverse function, users can adjust the delay time for reverse.

* Forward/reverse force controllable function.  *

* Auto detecting throttle position and hand setting some kind of fixed data

* Overheat protection(110℃).

* Power auto cutting when signal is lost from transmitter for 3 seconds.

* Without BEC output function, receiver need to connect power separately(BEC switching UBEC board, 5V,3A output can bring the speed and torque into fully play)

 Attention: The functions marked * can be set by Pro-box.
