4S 16V 12A PCB BMS Protection Board For 18650 Li-ion Lithium Battery Cell View larger

4S 16V 12A PCB BMS Protection Board For 18650 Li-ion Lithium Battery Cell

(SKU): HX-4S-A01/C55529

4S 16V 12A PCB BMS Protection Board For 18650 Li-ion Lithium Battery Cell

More details

In stock

4,00 € tax incl.

More info

  • 4S 16V 12A
  • 4 series 18650 battery 16.8V 16V 14.8V
    14.8V (Li-ion 18650 or li-ion battery rated voltage)
    16.8V (Li-ion battery full charge voltage)
    14.4V ( Lipo battery pack rated voltage)

    The lithium battery protection board is not included the welding tabs.

    Features:
    1) high-accuracy voltage detection circuit;
    2) terminal of the charger using high voltage device;
    3) Built-in three-stage over-current detection circuit (over-current 1, over-current 2, or load short circuit);
    4) MOS transistor can control the battery charge and discharge;
    5) low standby current consumption.

    P+/P- input/output interface, the same combination when the battery voltage, capacity, internal resistance should be matched well, combination without ouput, after the completion of voltage charging activation by 16.8V

    Specifications:
    Over Charge Voltage:4.25-4.35v±0.05v
    Over Discharge Voltage: 2.3-3.0v±0.05v
    Max Peak current: 6-8A
    Max instantaneous current: 12A
    Working Temperature: -40~+50℃
    Storage Temperature:-40~+80℃
    Static current: <30uA
    Life cycle: >50000hours
    Resistance: <100mΩ
    Charging Voltage: 16.8-17V
    Short cut Protection:Protectable ,change for repair
    Size: 7.2x1.3cm    /2.83x0.51inch
    Quantity: 1 Pc
