Specification:

• Brand new

• Size: approx.50*30*2mm

• Lampshift maximum discharge current: 15A

• Instantaneous discharge current: 25A

• Charging voltage: 25.5V

• Charging current: 15A (MAX)


• Overcharge detection voltage: 4.28 ± 0.05V

• Overcharge protection delay: 0.1S

• Overcharge release voltage: 4.08 ± 0.05V

• Over discharge detection voltage: 2.55 ± 0.08V

• Overdischarge detection delay: 0.1S

• The overdischarge release voltage: 2.9 ± 0.1V

• Overcurrent detection voltage: 150mV

• Overcurrent detection delay: 9MS

• Overcurrent protection current: 30 ± 3A

• Overcurrent protection release condition: Disconnect the load

• Short circuit detection delay: 250uS

• Short circuit protection Release condition: disconnect negative open

• Main circuit conduction resistance: ≤20mΩ

• Working current: ≤30uA

• Sleep current (battery over discharge) ≤10uA

• Temperature range: -30 / + 80 ℃
