OUTRUNNER C SERIES

ELE C05 / 3700KV

View larger

Display all pictures

ELE C05 / 3700KV

Reference: (SKU): M-1113

ELE C05 / 3700KV

In stock

Print

More info

ELE C05
KV	3700
Winding Material	silver-plating line
Weight	4.6g
Size(mm)	14 X 12
Shaft Diameter(mm)	1.5
Shaft Length(mm)	5
No load Current	10V 0.35A
Max Continous Current	3A
Surge Current	3.5A
Max Power	18W
Recommended Prop.	3*2
Recommended Battery	2S

Motor: C05M KV:3700

Tested with AEO E-Power 5A ESC						Weight :		4.6 grams
No Load Data:						Max. Power :		3A or 30W
7V	0.21A					Dimension:		13.9 x 17(mm)
8V	0.25A					Length of shaft:		5(mm)
10V	0.31A					Diameter of shaft:		1.5(mm)

Prop	Volts	Amps	Watts	RPM	Pitch Speed(m/s)	Thrust (g)	Thrust (oz)	Efficiency(g/W)	Efficiency(oz/W)
2510 GWS
	7	0.73	5.11	22610	14.84	28.2	0.99	5.52	0.19
	7.5	0.80	6	24380	16.00	32.8	1.16	5.47	0.19
	8	0.87	6.96	25700	16.86	36.7	1.29	5.27	0.19
	9	1.01	9.09	28500	18.70	41.2	1.45	4.53	0.16
	10	1.18	11.8	31050	20.37	51.2	1.81	4.34	0.15
	11.1	1.41	15.651	33850	22.21	61.2	2.16	3.91	0.14
3020 GWS
	7	1.82	12.74	16220	21.29	45	1.59	3.53	0.12
	7.5	2.00	15	16680	21.89	50	1.76	3.33	0.12
	8	2.19	17.52	17300	22.70	54	1.90	3.08	0.11
	8.5	2.30	19.55	17850	23.43	58	2.05	2.97	0.10
4025 GWS
	7	2.80	19.6	13000	17.06	65	2.29	3.32	0.12
	7.5	3.00	22.5	13300	17.45	68	2.40	3.02	0.11
	8	3.40	27.2	13500	17.72	72	2.54	2.65	0.09
	8.5	3.60	30.6	13800	18.11	78	2.75	2.55	0.09
5030 GWS
	7	3.20	22.4			68	2.40	3.04	0.11
	7.5	3.50	26.25			72	2.54	2.74	0.10
	8	3.80	30.4			76	2.68	2.50	0.09
	8.5	3.80	32.3
