Size?17cm*8.5cm*20cm
Weight? 0.85kg
Transmitting on 2.4G band
Modulation: FHSS
Power supply: 9.6V Ni-Cd battery or 12V alkaline battery
Current drain: 250mA
Trim: Mechanical
No EXPO function

Receiver: R7EH
R7F narrow band, 2.4GHZ 7 channel receiver
Power requirement: 4.8V~6V
Current drain: 9.5mA & 4.8V

Standard Channel displays
Channel 1: Aileron; Channel 2: Elevator; Channel 3: Throttle; Channel 4: Rudder

Features

1?   Transmitter hops spectrum while powering on
Transmitter will detect whether the current spectrum channel was occupied when its power on, and it will hop to the next one until where its not occupied. The receiver will search and match with the transmitter which has the same identity code.

2?   Code matches wirelessly
Each transmitter has an unique identity code of its own, the receiver will search and bind with the nearest transmitter when press the code matching button on it. There is no need to match again in future use once its matching successfully.

3?   High anti-interference capability
Adopt FHSS technology makes our products have excellent anti-interference capability. And helps the models always be in control easily.

4?   High suppression ratio of Adjacent Channels

5?   Fully comply with FCC&CE standards

6?   Stable RF range
With FHSS technology, its control range reaches 400 meters on ground and 800 meters in air.

7?   Flexible throttle hand change

8?   LCD screen, manual programming is enable. Including settings about D/R, SERVO REVERSING, EXPO, EPA, TRIM, N-TH, N-PI, I-TH, I-PI, GYRO, SWSH and etc.

9?   Low voltage warning function

10?Trainer cable, power charging jack.
