Features:

1.The new program algorithm designed for the car model has excellent starting effect, acceleration performance, braking performance and linearity;
2.Support all non inductive (i.e. no Hall sensor) brushless motors;
3.High quality materials with strong current resistance;
4.It has three operation modes: forward belt brake (one-way), forward and reverse belt brake (two-way) and direct forward and reverse (climbing car);
5.Maximum reversing force adjustment of 4 sections;
6.Proportional braking: 4-stage maximum braking force adjustment, 8-stage drag braking force adjustment, 4-stage initial braking force adjustment;
7.Nine kinds of kick-off acceleration (punch) adjustment, from "soft" to "very strong", in order to adapt to the characteristics of different models, tires and venues;
8.Multiple protection functions: low voltage protection (supporting lithium battery and NiCd / MH battery), temperature protection, throttle out of control protection, locked rotor protection;
9.The software is used to adjust the entry angle, with 8 entry angle modes, which can well match all kinds of brushless motors;
10.Single key programming, and single key to restore factory settings;
11.Support a variety of parameter programming methods: set button and parameter programming card (LED display) can be used

Specifications：
Cont./ Burst Current:18A / 25A
Resistance:0.01 ohm
Suitable Car：1/24
Battery：4 cells NiMH or 2 cells Li-Po
BEC Output：6V/1A（When using NiMH Battery, BEC = Battery voltage）
Dimension:31.5mm(L) * 24mm(W) * 15mm(H)
Weight:10g

Programmable Items:(Those "black backgroud and white text" options are the factory default settings)

1625 brushless motorSpecification:

1: 28 mosquito car accessories 1625 brushless motor 6000kv strong torque mini-q AWD.

For mini-z awd, iw05, iw04m, dg04m, bz, Mini-q, Mini-d, AMZ, DIY's 1:28portal, etc.

Size:16mm in diameter, 25mm in length, kv6000 supports 2S lithium 7.4v shaft, 2.0mm round shaft with M2 die for bearing screw.

Package List:
