CopterX CX450BAMB4 Black Angel Four-blades Helicopter

(SKU): CX450BAMB4-RTF

CopterX CX450BAMB4 Black Angel Four-blades Helicopter

Περισσότερες λεπτομέρειες

Διαθέσιμο

350,00 € με Φ.Π.Α

-30,00 €

380,00 € με Φ.Π.Α

Άλλες πληροφορίες

.

Arrived with 100% Assembled
Black Angel is one of the most advance 450 size 3D helicopter on the market. With it’s innovative design and robust construction. Black Angel is able to offer performance rivals can only dream of. This RTF model will come 100% assembled, tuned and ready to fly.

  • +/- 15 extra wide pitch range
  • Over sized feathering shaft, screws, blade grip bearing, main shaft collar, etcfor maintenance free operation
  • 240 reinforced swash plate for positive response
  • One piece CCPM swash plate design for durability
  • Simple head design for quick output and easy maintance
  • Fully ball raced capable to handle head speed of over 3500rpm and tail speed for over 13600rpm
  • Extra wide drive belt for trouble free and quick operation
  • Direct tail drive system weight saving and quicker response
  • Extra wide drive belt to ensure non slip and sensitive rudder control
  • High strength nylon main gear for quite and smooth operation
  • Precise high wear resistance aluminum alloy pulley set
  • One piece carbon fiber main frame for strength and durability
  • Light weight carbon fiber bottom plate, ESC mount, battery mount and anti rotation bracket
  • High strength aluminum alloy tail boom look
  • Aluminum alloy rudder servo mount
  • Light weight one piece composite landing skid
  • Plastic Canopy mounts to isolate canopy vibration
  • Light weight high strength glass fiber per painted canopy

Features:

  • CNC multi-blades rotor head system by high strength light weight aluminum
  • High strength almuninum plate for positive response
  • Special designed scale rotor blades especially for scale flight application
  • One piece CCPM swash plate design for durability
  • Fully ball raced
  • Extra wide drive belt for trouble free and quick operation
  • Direct tail drive system weight saving and quicker response
  • Extra wide drive belt to ensure non slip and sensitive rudder control
  • High strength nylon main gear for quite and smooth operation
  • Precise high wear resistance aluminum alloy pulley set
  • One piece carbon fiber main frame for strength and durability
  • Light weight carbon fiber bottom plate, ESC mount, battery mount and anti rotation bracket
  • High strength aluminum alloy tail boom look
  • Aluminum alloy rudder servo mount
  • Light weight one piece composite landing skid
  • Plastic Canopy mounts to isolate canopy vibration
  • Light weight high strength glass fiber per painted canopy



    • Specification:



  • Length: 653mm
  • Height: 240mm
  • Main Rotor: 714mm
  • Tail Rotor: 157mm
  • Motor Gear: 12T/13T
  • Main Gear: 150T
  • Autorotation Tail Drive Gear: 43T
  • Tail Drive Gear: 10T
  • Drive Gear Ratio: 1:12.5:4.3(12T) / 1:11.54:4.3(13T)
  • Weight(without electric parts): 370g
  • Weight(including electric parts): 760~800g
  • Box dimension: 695*275*170mm




.CopterX CX450 AE V2 / SE V2 / ME RTFWalkera Creata 400ESKY Belt CP V2
Length653mm590mm640mm
Main Rotor diameter714mm622mm680mm
Tail Rotor diameter157mm135mm130mm
Weight including power system760g~800g628g670g
Battery11.1V 2200mAh11.1V 1500mAh11.1V 1800mAh
Skill Levelrate_5.gifrate_4.gifrate_4.gif
.

Package Included:

  • CopterX CX450 Black Angel Four-blades Kit x 1
  • CopterX 2.4G Transmitter & Receiver x 1
  • CopterX (CX-9G) 9G Servo X 3
  • Fusonic (MG-D-9257-V2) 9257 25g Metal Gear High Speed Mini Digital Servo X 1
  • CopterX (CX-GY240) Gyro GY240 X 1
  • CopterX (CX-ESC-40A) 40A V2 Brushless Electronic Speed Controller X 1
  • CopterX (CX450-10-04) 430XL Brushless Motor (3550KV) X 1
  • Full Size Paper Case x 1
  • CopterX Balance Charger x 1
  • CopterX Li-Polymer Battery 11.1V 15C 2200mAh x 1
  • All helicopter were setup and tested by skilled technican before delivery
  • As 2.4Ghz technology do not require any frequency contorl. Makes this mode a lot safer to operate and don't have to worry about bringing the wrong crystal to the flying field
  • Design for EXPERT pilot
