Description：

SCUD series are very strong and powerful FPV motors for FPV racing, great value choice with well known SCUD performance.focuses on quality, the SCUD series affordable motors that are strong and durable.

This 2207 2306 sized motor features a High-strength 5mm steel hollow shaft, Single strand windings for performance, M3 shaft screw.

Features:

High-strength 5mm Steel shaft

N52H High-temperature magnets, NSK bearings

16x16mm hole pattern

Single strand copper winding

Hex bolt shaft set screw

2207 Specifications:

Model: SCUD 2207 Motor

KV: 1850KV / 2550KV

Weight(included wire): 33g

Dimension: φ28.5*19.4mm

Interphase Resistance: 78.23mΩ / 44.31mΩ

Peak Current: 42A / 50A

Max Watt: 1000W / 800W

Configuration: 12N14P

2306 Specifications:

Model: SCUD 2306 Motor

KV: 1750KV / 2500KV

Weight(included wire): 34g

Dimension: φ29.5*18.8mm

Interphase Resistance: 87.65mΩ / 55.88mΩ

Peak Current: 45A / 50A

Max Watt: 1000W / 800W

Configuration: 12N14P
